Eflite 26g Digital MG Mini Servo
Product Specifications
Max Servo Torque
40-99 oz-in
Product Weight
1.09oz
Product Length
1.74 in
Rotation Range
200deg
Product Width
0.7 in
Product Height
1.5 in
Servo Type
Digital
Servo Size Category
Mini
Maximum Servo Speed
0.14 sec/60 deg at 4.8V; 0.11 sec/60 deg at 6.0V
Maximum Servo Torque
65 oz/in at 4.8V; 78 oz/in at 6.0V
HPI 120019 Ss-30Mgwr Servo (Waterresistant/6.0V/8Kg/Met. Gear
This water-resistant metal geared servo is ideal for bashers and racers looking for a tough and durable servo that can be used in wet conditions (e.g. rain, snow, puddles). Please note, not suitable for submersion.
Features:
Operating Voltage: 4.8-6V
4.8V: Speed: 0.19 sec/60 degrees, Torque: 6kg-cm
6V: Speed: 0.15 sec/60 degrees, Torque: 8kg-cm
Servo Spline: 25T
Dimensions:
Main case: 40.7x39.4x20.0mm (excluding mounting tabs, servo spline, & cable outlet)
Mounting tab hole centres: 50.0x9.8mm
Weight: 56g (excluding servo horn)
NOTE: This servo is water-resistant only, meaning it is resistant to splashes and brief contact with water. It is not waterproof and therefore not suitable for submerged used. Before driving in wet conditions, make sure that all electronics fitted to the vehicle are safe to use (marked as water-resistant or waterproof), or that they are fully enclosed and protected from water and moisture (such as in a sealed receiver/battery case). Fans mounted on speed controllers are not water resistant - we recommend to disconnect the fan from the ESC before driving in wet conditions and allow it to dry fully before reconnecting the fan power. Lubricate exposed metal drivetrain parts such as bearings, outdrives and diff shafts before driving in wet conditions. Motors are not intended for submerged use and may be damaged if used when under water. After driving in wet conditions, make sure to rinse off dirt and any corrosive liquids like saltwater with plain water and re-lubricate metal drivetrain parts.
HPI 160544 SD-07WR
This water-resistant servo is ideal for bashers and racers looking for a tough and durable servo that can be used in wet conditions (e.g. rain, snow, puddles).
Features:
Operating Voltage: 4.8-6V
4.8V: Speed: 0.18 sec/60 degrees, Torque: 6kg-cm
6V: Speed: 0.16 sec/60 degrees, Torque: 7kg-cm
Servo Spline: 25T
Dimensions:
Main case: 40x37.5x20.0mm (excluding mounting tabs, servo spline, & cable outlet)
Mounting tab hole centres: 49.5.0x10mm
Weight: 46g (excluding servo horn)
NOTE: This servo is water-resistant only, meaning it is resistant to splashes and brief contact with water. It is not waterproof and therefore not suitable for submerged used. Before driving in wet conditions, make sure that all electronics fitted to the vehicle are safe to use (marked as water-resistant or waterproof), or that they are fully enclosed and protected from water and moisture (such as in a sealed receiver/battery case). Fans mounted on speed controllers are not water resistant - we recommend to disconnect the fan from the ESC before driving in wet conditions and allow it to dry fully before reconnecting the fan power. Lubricate exposed metal drivetrain parts such as bearings, outdrives and diff shafts before driving in wet conditions. Motors are not intended for submerged use and may be damaged if used when under water. After driving in wet conditions, make sure to rinse off dirt and any corrosive liquids like saltwater with plain water and re-lubricate metal drivetrain parts.
Multiplex SERVO MS8510MG DIGITAL
Perfekt servo for indoor fly. Eventuelt fly av micro størrelse. Med sin lille fysiske størrelse 8x23x20mm – OG sine beskjedene 5gr
Informasjon på engelsk:
The new multiplex indoor servo.
The MS-8510MG Digital is specially designed to meet the needs of indoor pilots.
It’s fast, strong, and precise.
Has a sturdy aluminum gear. (Finally no more “caries” after a contact with the ground, as with so many other micro servos with plastic gears)
An extra large servo lever is perfect for rope and rod linkage.
Last but not least, thanks to the “honest” 60 degree path, large deflections are possible at full power.
Look forward to many nice flights with the new MS-8510MG Digital
The MS-8510Mg Digital is also perfect for F3K, HLG and other models.
Bredde: 8 mm
Høyde: 23mm
Lengde: 20mm
Vekt: 5gr
Servotype: Mikro
Spesielle funksjoner: digital
Gear: metall
Driftsspenning i V: 4,8-6,0 V.
Posisjoneringstid s / 60 ° ved 6,0 volt: 0,06
Moment i kg/cm ved 6,0 volt: 1
Tanning: 5
Kulelager: Nei.
Vanntett: Nei
DREV
Metall
HASTIGHET
0.06
MERKE
Multiplex
SPENNING
4.8V, 6.0V
SPLINE
15
STØRRELSE
Nano
TIL
Fly
TORQUE
1kg
TYPE
Digital
VEKT
5g
Tekin T-440 Digital Hi-Torque Programmable Servo (High Voltage)
Hit the trails hard with the Tekin T-440 Crawler Servo. Rocks, Mud, Dirt or Snow. The Element Proof Design means you can tackle any terrain. Full Metal Gear set, All Aluminum Housing, Digital Position Encoding and loads of Torque, this servo keeps you out of a bind. Fine-tune your setup with an extensive set of adjustments via Tekin’s HotWire PC Interface.
The Difference is in the Design
Tekin servos are crafted from the highest quality materials available. CNC Precision Cut gears provide an extremely smooth and efficient drive train. 6061-T6 machined aluminum 3-piece o-ring housings provide strength and protection from the elements while the finish quality and design are second to none. Sleek chamfered edges and bold lines combined with a matte anodized finish are sure to accent any build.
Included with the T-440 Servo is a machined aluminum 20mm Crowbar 25T dual clamping servo arm.
Advanced Technology:
Digital Magnetic Position Encoder (DPE): Our servos use Digital Magnetic Position Encoding (DPE) rather than a standard potentiometer, which gives Tekin servos industry leading accuracy, linearity and consistency.
Accuracy: Precise linear movement through the entire motion range with less than .2 degrees of deviation from start point to end point make Tekin the superior performance product. Low deviation DPE technology translates to pinpoint accuracy not found in other potentiometer servos, which tend to wander and center poorly and get worse as they age. Tekin is built to last at peak performance.
Linearity: Potentiometer servos can be up to seven degrees non-linear from end point to end point, creating a disconnected feel from your transmitter. Tekin servos eliminate this disconnect, giving you a linear feel and more precise control over your servo movement and position.
Consistency: Performance is important but we are all about consistent performance. Potentiometer performance drifts due to many variables; heat, age, component quality, etc. DPE is a rock-solid, repeatable and consistent technology bringing an unmatched consistency to Tekin servos. Tired of constantly trimming your servo and having response feel different during times of longer usage? Tekin servos are the answer.
Efficiency: Accuracy drives efficiency. A servo that has to work less to center or stop without overshooting position is using less energy. This means less heat build-up, less component fatigue and longer life.
Adaptability: Tekin Servos come with a series of unique features; DPE technology lets you set the center point anywhere, and servo travel limits can be set without reducing the End Point Adjustments (EPA’s) on your transmitter. Most servos are limited to 90° travel in each direction with a physical stop point; DPE means that Tekin servos can be programmed to travel beyond 360°-- up to 5 full rotations in each direction!
Element Proof: Dependable, no matter the terrain. Element Proof Tekin products are designed to handle water, mud & snow within reasonable restrictions. While we are not afraid to take on the elements, submerging is not recommended.
Features:
Digital Magnetic Position Encoder (DPE)
Specifically Designed for 1/8 and 1/10 Scale Applications
Included Aluminum Vector Servo Arm
Full Aluminum Servo Housing
Element Proof Design*
Precision Cut Full Metal Gears
ABEC5 Ball Bearings
High Voltage Capable
High Torque Coreless Motor
25T Output Spline
Programmable via HotWire PC Interface
Overload Protection Technology
Thermal Protection Circuitry
Low Voltage Alarm**
Quiet, Efficient, Cool Operation
HDAC: High Density Copper PCB's
*Tekin Element Proof products are designed to withstand water, snow and mud. Not intended for operation while submerged in liquid.
**requires HotWire sold separately
HotWire Programmable Features:
Feel - Mild to Aggressive
Speed Limit
Torque (0-100%)
Torque Delay
Direction - Normal / Reverse
Center Point
Travel
Soft Starting Speed & Torque
Max Temp Alarm
Low Voltage Alarm
Over Voltage Alarm
Bind Relief
Fail Safe Speed and Position
Set Custom Servo Name
Specifications:
Size Category: Standard
Type: Digital
Application: Rock Crawling and Rock Racing
Torque: 502 oz-in (36.2kg-cm) @ 8.4V; 460 oz-in (33.1kg-cm) @ 7.4V; 421 oz-in (30.3kg-cm) @ 6.0V
Speed: 0.11sec/60 deg @ 8.4V; 0.13sec/60 deg @ 7.4V; 0.15sec/60 deg @ 6.0V
Length: 1.57 in (40mm)
Width: 0.79 in (20mm)
Height: 1.57 in (40mm)
Weight: 2.57 oz (73g)
Bushing Or Bearing: Bearing
Motor Type: Coreless
Gear Type: Metal
Voltage: 4.8V to 8.4V
