Sweden's Scania Company known as a large truck and bus maker. It is the company's flagship, one of the R series that won the International Truck of the Year 2005, completed 1/14 electric RC truck which reproduced the R470 high line. Using aluminium channel material as side rail, ladder frame combined resin cross member, metal leaf spring and front and rear suspension equipped with metal damper with built-in coil spring Attractive chassis structure. Gear change is possible by RC operation with 3 speed transmission as standard equipment. In addition, the body which realistically modelled a powerful form using a precision mould, finished with a high sense of scale, such as setting a resin net for the front grill. Moreover, like the actual car, the cab can be tilted leaving the fender, and the interior of the fender was reproduced. It is a trailer head that can fully enjoy the fun of the assembly and the fun of running and can enjoy the long distance tracker feeling.
Set med E-ringer. Kan brukes alle steder hvor du trenger E-ringer, men sjekk med din manual for å få riktig størrelse.
Settet inneholder følgende størrelser:
10x E-Ring 2mm
2x E-Ring 3mm
5x E-Ring 4mm
This is a 1/14 Scale Tractor Truck by Tamiya which is a VERY Scale Kit. The
semi trailer is Not Included in this kit, but is available separately (or the tanker trailer).
FEATURES: 3-speed transmission with constant mesh gears
Metal rail chassis
Scale suspension with heavy duty metal leaf-springs and coil
spring dampers
Propeller-shaft driven rear axles (both axles are used to drive
the truck)
Numerous scale body accessories including metal grab rails and
side mirror supports, metal dual exhaust pipes and chrome plated
parts (grille,fuel tanks, side steps, horns, wipers, visor,
rims, bumpers, light mounts, mirrors and tire guards)
Oilite bearings (bushings)
INCLUDES: Injection molded body (White) and truck interior
10 scale appearance rims and tires
540 motor
Decal sheet (with license plate decal for bumpers)
Mud flaps
Illustrated instructions
REQUIRES: Radio: 4-channel with 4-channel receiver and analog or digital trim
function
**Important-if using the Multi Function Control, see COMMENTS**
Electronic Speed Control: Tamiya TEU302BK (45028) recommended, do
not use the Tamiya TEU101BK or the TEU104BK
6-cell flat pack (or 7-cell hump)
Charger for battery pack
Paint
SPECS: Length: 23.62"
Width: 7.09"
Height: 10.04"
Weight (with radio installed): approx. 7lbs
Low (1st) gear ratio: 1:32.49
Middle (2nd) gear ratio: 1:17.66
Top (3rd) gear ratio: 1:10.66
COMMENTS: The Tamiya Multi Function Control Unit (56511) not included,
provides many different truck related sound effects. The Multi
Function Control Unit REQUIRES an FM type radio only with analog
trims such as the Futaba 4YF
This is a 1/14 scale Tractor Truck by Tamiya which is a VERY Scale Kit. The
Semi Trailer is NOT included in this kit, but is available separately 56302
(or tanker trailer, 56303). .
FEATURES:
3-speed transmission with constant mesh gears
Metal rail chassis
Scale suspension with heavy duty metal leaf-springs and coil spring dampers
Propeller-shaft driven rear axles
Numerous scale body accessories including metal grab rails and side mirror supports, metal dual exhaust pipes and chrome plated parts (grille, fuel tanks, side steps, horns, visor, rims, bumpers, light mounts, wipers, mirrors and tire guards) Oilite bearings (bushings)
INCLUDES:
Injection molded body (white) and truck interior
10 scale appearance rims and tires
540 motor
Decal sheet (with license plate decal for bumpers)
Mud flaps
Illustrated instructions
REQUIRES:
Radio: 4-channel with 4-channel receiver and analog or digital trim function
**Important-if using the Multi Function Control, see COMMENTS**
Electronic Speed Control: Tamiya TEU302BK recommended, do not use the Tamiya TEU101BK or the TEU104BK
6-Cell Flat Pack (or 7-cell hump)
Charger for Battery Pack
Paint
SPECS:
Length:
19.69"
Width: 7.20"
Height: 10.35"
Weight (with radio installed): approx. 7lbs
Low (1st) gear ratio: 1:32.49
Middle (2nd) gear ratio: 1:17.66
Top (3rd) gear ratio: 1:10.66
COMMENTS:
The Tamiya Multi Function Control Unit, not included, provides many different truck related sound effects.
Tamiya 56305 1/14 MERCEDES-BENZ 1838LS
The 1838LS tractor truck combines a massive aerodynamic silhouette with a powerful 380 horsepower, 12,763cc V8 cylinder turbo diesel engine. Tamiya's R/C model of the 1838LS truck realistically captures the looks of the full size truck.
Specifications
Scale: 1/14
Length: 17.44 inches (443mm)
Width: 7.44 inches (189mm)
Wheelbase: 10.71 inches (272mm)
Front Tread: 6.14 inches (156mm)
Rear Tread: 5.43 inches (138mm)
Weight: 5 lbs. (2270g)
Chassis: Aluminum ladder
Suspension: Solid Axle
Damper Type: Metal friction
Drive Train: Gearbox (3-speed)
Gear Ratio: 10.6:1 - With the 3-speed gearbox, 10.6:1, 17.7:1 and 32.4:1 are possible
Differential Type: Bevel Gear
Engine: Electric 540
Wheels & Tires: Chrome/Radial
Body Type: Styrene(plastic)
Radio Control Unit: (not included) Can be operated with a 2-channel radio but a 4-channel system is recommended for potential future options.
Battery: Requires a 7.2V battery and charger
Spare Parts & Hop Up Options
56501 - Tractor truck electrical unit set
56503 - Tractor truck oil shocks
56507 - Telescopic antenna
56508 - Truck aluminum front wheels (1 pair)
56509 - Truck aluminum rear wheels (1 pair)
56510 - Tractor truck sound effects set
TAMIYA FLATBED SEMI-TRAILER
This highly realistic 1/14 scale flatbead semi-trailer model is for use in combination with Tamiya's 1/14 R/C tractor truck. A scale appearance is achieved by using authentic components such as aluminum chassis/frame, wood-floored platform and actual chains.
Used with:
It is for use with the Tamiya 1/14th scale tractor trucks, such as the King Hauler, Mercedes-Benz, or
Globe Liner and many more.
Includes:
Decals
Extruded Aluminum Frame Construction
Wooded Floorboards
Actual Chain Tiedowns
Working Supension
Rubber Tires and Chrome Wheels.
Specifications
Scale: 1/14
Length: 27.99 inches (711mm)
Width: 7.60 inches (193mm)
Rear Tread: 5.43 inches (138mm)
Weight: 5.47lbs. (2480g)
Chassis: Aluminum ladder
Suspension: Solid Axle
Damper Type: Metal friction
Wheels & Tires: Chrome/Radial
Spare Parts & Hop Up Options
56502 - Semi-trailer light set
56503 - Tractor truck oil shock set
56505 - Motorized support legs
56509 - Truck aluminum rear wheels (1 pair)
1/14 RC Trailer Head King Howler Metallic Special
This is the electric powered, radio controlled, 1/14 scale Tamiya Metallic Special King Hauler Tractor Truck kit. Compatible with the Tamiya Tractor Truck Option Parts for further customization.
FEATURES:
Chassis: Ladder frame with aluminum channels and resin cross members
Cabin: Tilt forward operation just like full-size truck, removable fenders to depict a low carrying load
Drive: Shaft driven from front mounted motor to rear axles which are equipped with differentials Motor: RS540
Transmission: Three speed servo controlled constant mesh
Suspension: Die cast metal front axle and reinforced resin rear axles float mounted on metal leaf springs and coil spring shocks
Cabin: Molded plastic chrome finish, tilts forward separately from fenders, clear plastic windows, separate grille, mirrors, seats dashboard and other accessories add to realism
Body: Polystyrene resin with vacuum metalized plating
Wheels: Chrome plated plastic
Tires: Ten, treaded rubber construction
INCLUDES:
1/14 scale Tamiya Metallic Special King Hauler
540 motor
tires, wheels
decal sheet
3-speed transmission
instructions and coupler unit for trailer (trailer not included)
REQUIRES:
Radio: 4-channel with 4-channel receiver and analog or digital trim
function
**Important-if using the Multi Function Control, see COMMENTS**
Servos: Two standard size for steering and shifting
Electronic Speed Control: Tamiya TEU302BK recommended, do
not use the Tamiya TEU101BK or the TEU104BK
Battery: 6-cell stick
Battery Charger: Timed or peak for 6-cell battery
Paint, building & track equipment
SPECS:
Length: 23.6" (600mm)
Width: 7.1" (180mm)
Height: 10" (255mm)
Gear Ratio: Low Gear 1:32.49
2nd Gear 1:17.66
3rd Gear 1:10.66
COMMENTS:
The Tamiya Multi Function Control Unit not included, provides many different truck related sound effects. The Multi Function Control Unit REQUIRES an FM type radio only with analog trims such as the Futaba 4YF
