This is the CC BEC 10A Receiver Battery Eliminator by Castle Creations.
FEATURES: Eliminates the need for a receiver and servo battery pack
Draws higher voltage from the motor batteries and drops it to a
voltage level suitable for the receiver and servos
INCLUDES: One CC BEC receiver battery eliminator
REQUIRES: Installation in the aircraft
SPECS: Length: 1.2" (30mm)
Width: .6" (15mm)
Height: .4" (10mm)
Weight: .4oz (11g)
Input voltage: 5V to 25.2V (2S to 6S LiPo)
Current output: 12 volts input = 7 amps* continuous, 10 amp peak;
24 volts input = 5 amps* continuous, 7 amp peak
*Ratings are determined with a 5mph airflow on the BEC
Selectable Output: 4.8 - 9.0V via the Castle Link (sold separately)
Default voltage is 5.1V
Castle Creations makes the best electronic speed controllers in the industry, possibly the world! Our engineers have spent countless hours integrating features and firmware that no other manufacturers can match.
Speed Controllers enabled with SmartSense use the motor’s sensors to provide smooth starts, excellent torque, and low-speed drivability. Once the motor is turning, it seamlessly transitions to Castle’s ULTRA-EFFICIENT sensorless mode with electronic timing. When running, a motor must transition between different load points and a different timing advance is required for optimal efficiency at each. Electronic timing in SMARTSENSE™ will advance timing automatically for peak performance during all driving conditions. This combines the best of both worlds in an unrivaled HYBRID between smooth sensored startups and high-efficiency sensorless running. Your motor will produce more power and less heat.
