This is the 1/10 scale electric powered, radio controlled, 4WD
Mercedes Benz Unimog 425 Off-Road Kit from Tamiya.
FEATURES
Chassis: CC-01, plastic tub construction
Drive: Four wheel drive, shaft driven
Motor: 540 size brushed electric motor
Electronic Speed Control: TBLE-02S
Lights: Tamiya TLU-01 5mm LED light unit with two front
and two rear LED lights in metal plated light cases see COMMENTS
Shocks: Oil-filled, black plastic construction
Gearbox: Front and rear sealed gearbox
Differentials: Planetary gear
Transmission: Single speed
Tires: Semi-pneumatic all-terrain, rubber construction
Wheels: One-piece, black ABS resin wheels
Body: Polycarbonate, separate snorkel and cap, emblem cap and side
mirrors
Bumper: Front, plastic construction, black in color
Suspension: Front, long stroke double wishbone
Rear, four link solid axle
Camber Tie Rods: Fixed non-adjustable
Caster: Adjustable, caster/toe-in refers to the angle of the front
suspension when viewed from the side of the car in relation to the
chassis
Steering: Bell-crank type with servo saver and adjustable linkage
INCLUDES
Tamiya Unimog 425 kit with oil-filled shocks, 540 motor, ESC,
clear body, tires, wheels, LED light kit, shock oil, 16 tooth
pinion gear, spur gear, instructions
_
REQUIREMENTS
Radio: 2-Channel with 1 Servo
Eight AA batteries for transmitter
Battery: 7.2V 6-cell stick pack w/ standard connector
Charger: AC/DC timed or peak for 6-cell battery
Misc. Items: Building and track equipment
SPECIFICATIONS
VEHICLE-
Length: 16.8" (426mm)
Width: 7.7" (195mm)
Height: .5" (215mm)
Weight: 53.3oz (1510g)
Wheelbase: 9.9" (252mm)
BODY-
Length: 15.8" (402mm)
Width: 7.0" (178mm)
Height: 6.1" (155mm)
COMMENTS
To paint body to match color scheme on box, order the following
Tamiya colors;
PS-5 Black, PS-21 Park Green,
PS-7 Orange, PS-31 Smoke
